Body Material: ABS
Size: 116*82*18mm (4.57″*3.23″*0.71″)
Filling: Epoxy+Quartz sand
Lens Material: PMMA
Solar Stud For Road Features:
•Solar Stud For Road water, oil, chemical, and heat resistance.
•Solar Stud For Road can work more than 3 years normally.
•Very high reflectivity.
•Solar Stud For Road easy installation with glues.
•Photometric values:exceeds 600(mcd/lux).
Solar Stud For Road Parameters:
| Body material: | ABS |
| Filling: | Epoxy+Quartz Sand |
| Lens Material: | PMMA |
| Reflector type: | Double side/Single side |
| Quality: | ASTM D4280 & EN1463-1 standard |
| Size: | 116*82*18mm (4.57″*3.23″*0.71″) |
| Packing: | 23.5*8.5*19.5cm,100pcs/ctn (9.25″*3.35″*7.67″,100pcs/ctn) |
| Weight: | 110g/pc; 11kg/ctn (0.24bs/pc; 24.25bs/ctn ) |
Installation Method Of Plastic Solar Stud For Road:
1. Determine the installation location and distance, clean the road surface, and ensure that the Plastic Solar Studs For Road are installed on a flat road surface.
2. Clean the bottom of the Solar Studs For Road and apply the epoxy glue evenly to the back of the studs.
3. Press the side with the glue on the road, fix the position, wait for the glue to dry.
4. Check within 2 hours of installation to ensure that all Solar Studs For Road are not installed incorrectly and are not bent or deformed due to compression.
5. Remove the installation isolation facility within 6-8 hours after the installation of the Solar Studs For Road.
